4-10 Section 4-3 - General Procedure
4-3-6 B Mode Checks
4-3-6-1 Preparations
1.) Connect one of the probes listed in 3-6-6 "Available Probes" on page 3-26, in Chapter 3 Installation
to the System probe connector.
2.) Turn ON the scanner (if it isn’t turned on already)
Figure 4-8 Controls available in B Mode
Figure 4-9 B Mode Screen Picture Example
B Mode
Secondary Menu
Frame Average
Biopsy Kit
Line Density
Focus Width
B Softner
Suppression
Power Output
Depth
Freeze
SoftMenu Key
Primary Menu
Frequency
Virtual Convex
Gray Map
Dynamic Range
Rejection
Focus Position
Colorize
Edge Enhance
Rotation
Focus Number
Zoom
Scan Area
To Next Page
