GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-3
8-2-3 Standard tools list for LOGIQ P3
NOTE: Please use the correct Screwdrivers listed in Table 8-1 on LOGIQ P3.
NOTE: After Replacement of the Hardware Boards on LOGIQ P3BT10, please perform Shutdown and
Reboot.
Table 8-1 Standard tools list
No Part Name Screw Description Screwdriver Description
1 screw Screwdriver, Stubby Phillips #2
2 screw 1/4 in. Standard.Socket set (19 pc) Xcelite-hex Blade 5/32 inch
3 screw Screwdriver, Slotted 1/4 in.X 6 in. Steel rule Metric 6 inch
4 screw Screw FH M2.5x3 (NL) Phillips #1
5 screw Screw SFH M2.5x4 (NL) Phillips #1
6 screw Screw FH M2.5x5 (NL) Phillips #1
7 screw Screw FHE M2.5x5 (NL) Phillips #1
8 screw Screw SJ2836-87 M2.5X6 (I) Phillips #1
9 screw SCREW SJ2836-87 M2.5x12 (II) Phillips #1
10 screw D2 SCREW M3X3-NYLOK Phillips #1
11 screw Screw FH M3X6 (NL) Phillips #1
12 screw D2 SCREW SJ2836-87 M3X8 Phillips #2
13 screw Screw BN5687 M3X10 (NL) TORX#10
14 screw Screw FH M3X13 (NL) Phillips #1
15 screw Screw SJ2836-87 M3X18 (I) Phillips #2
16 screw Screw M3x25 (NL) TORX#10
17 screw Screw M4x12 TORX#10
To Next Page
