GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
8-58 Section 8-5 - USB Cable Set (FRU P/N: 5315039)
8-5-2 Power distribution Board Assembly (P/N: 5370455), PDB Sub (P/N: 5370323),
PDB Sub (Part no.: 5397797) - LOGIQ P3BT10
8-5-2-1 Tools
• Common Phillips screwdrivers
8-5-2-2 Needed Manpower
• 1person, 15 minutes
8-5-2-3 Preparations
Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system
8-5-2-4 Removal Procedure
1) Loosen the two screws (A) and pull out the Cables which are connected to PDB as shown in rectangle
box (B) in the figure.
2) Remove PDB assembly.
Figure 8-65 Removing Hard Disk Drive Power cable
(B) Power cables
(A) Two Screws
(B) Power cable
To Next Page
