GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-29
4) Remove the keyboard rear cover as shown below Figure 8-31 on page 8-29
Figure 8-31 keyboard rear cover
8-3-0-5 Mounting procedure
1.) Install the new parts in the reverse order of removal.
8-3-0-6 Functional Checkout Procedure
Functional Test Debrief Script
Do Visual Inspection and ensure
no scratches observed and
fitment is done properly
Service Manual Direction 5308917-100, Section 8-3-1. Equipment passes all required
tests and is ready for use.
