GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-89
Section 8-13 Power Cable Set (FRU P/N: 5315036 for P3 and P/N: 5388845 for
P3 BT)
8-13-0-1 Tools
• Common Phillips screwdrivers
8-13-0-2 FRU BOM
This FRU Kit P/N:5315036 consists of following parts.
Note: This individual cables are not seperate FRUs, but are part of cable kit higher level FRU.
Table 8-3 LOGIQ P3 (5315036)
Table 8-4 LOGIQ P3 BT10
(5388845)
8-13-0-3 Needed Manpower
• 1 persons, 15 minutes per cable
8-13-0-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-13-0-5 Removal Procedure
1. Remove the covers and parts as applicable. Refer to the applicable section of this document.
2. Unplug the power cable from both the ends.
Part Number Description
5270783 Cable Assembly for Transformer to PS, SSR and Peripheral Connector
5262720 Cable Assembly for Panel mount connector to power supply & solid state relay
5262046 Peripheral Connector to Rear panel sockets
5269059 PDB to Conn Brd and MST Brd
5269791 LCD Power cable
5269919 Dual SATA Power Cable for PDB to HDD and DVD
5270870 PDB to KBD and Fan
5269067 Conn Brd to TXB
5263747 Docking Brd to RP2 FRC cable
5263844 MST to KBD & DVD SATA Signal cable
Part Number Description
5342775 Cable Assembly: 1 Power entry to PS, Relay and Printer
5342780 Power Assembly to Power supply and Relay Card_Cable assembly
5342888 PDB to Conn Brd, MST Brd and RP2 BRD_Cable Assembly
5366298 LCD DC Power cable
5269919 Dual SATA Power Cable for PDB to HDD and DVD
5270870 PDB to KBD and Fan
5269067 Conn Brd to TXB
5263844 MST to KBD & DVD SATA Signal cable
5342783 Power Supply output to PDB
5390435 POWER_SUPPLY_FAN_CABLE_ASSEMBLY
5342782 Cable assembly: 4 PDB to SBV board
