GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
4-20 Section 4-3 - General Procedure
4-3-9 Doppler Mode Checks
4-3-9-1 Preparations
1.) Connect one of the probes listed in 3-6-6 "Available Probes" on page 3-26, in Chapter 3 Installation
to the System probe connector.
2.) Turn ON the scanner (if it isn’t turned on already).
Figure 4-14 Controls available in Doppler Mode
Figure 4-15 Doppler Mode Screen Picture Example
Primary Menu
Secondary Menu
PW Mode
B Pause
Frequency
Baseline
Quick Angle
Sweep Speed
PRF
SV Length
Angle Steer
Angle Correct
Spectral Invert
Wall Filter
Rejection
Dynamic Range
Display Format
Full Timeline
Trace Method
Trace Sensitivity
Trace direction
Modify, Auto Calcs
PW/CF Ratio
Duplex
Time Resolution
Colorize
Gray Map
Power Output
Auto Calcs
Spectral Average
Cycles, to Average
M/D Cursor
Gain
B Pause
To Next Page
