Chapter 8 Replacement Procedures 8-41
8) Remove the top whole assembly by pulling the top assembly front side from the system. Refer Figure
8-46 on page 8-41
Figure 8-46 Top assembly
9) The top assembly should be to removed from two locating pins (A,B). Refer Figure 8-47 on page 8-41
Figure 8-47 Top assembly
8-4-5-5 Mounting procedure
1.) Install the new parts in the reverse order of removal.
8-4-5-6 Functional Checkout Procedure
Functional Test Debrief Script
Do Visual Inspection and ensure
no scratches observed and
fitment is done properly
Service Manual Direction 5308917-100, Section 8-4-5. Equipment passes all required
tests and is ready for use.
