GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
8-36 Section 8-4 - Mechanicals
6) Loosen Rear cover RH-Side from the system.Refer Figure 8-39 on page 8-36
Figure 8-39 Removing screws of rear cover
8-4-3-5 Mounting procedure
1.) Install the new parts in the reverse order of removal
8-4-3-6 Functional Checkout Procedure
Functional Test Debrief Script
Do Visual Inspection and ensure
no scratches observed and
fitment is done properly
Service Manual Direction 5308917-100, Section 8-4--3. Equipment passes all required
tests and is ready for use.
