IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
8-54 Section 8-4 - Mechanicals
3) Remove SATA cable from Hard disk drive assembly Refer Figure 8-62 on page 8-54
Figure 8-62 Removing SATA cable
8-4-11-5 Mounting procedure
Install the new parts in the reverse order of removal.
8-4-11-6 Functional Checkout Procedure
See
Section Functional Test Debrief Script
4-3-1 Power On/Boot Up
Service Manual Direction 5308917-100, Section 8-4-11. Equipment passes all
required tests and is ready for use.
4-3-2 Power Off/ Shutdown
Sata Signal Cable
Power cable
To Next Page
