GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-37
8-4-4 Front Cover (FRU No.5315116)
This is a description on how to remove and replace the Front Cover.
8-4-4-1 Tools
• Common Phillips screwdrivers
8-4-4-2 Needed Manpower
• 1 persons, 15 minutes
8-4-4-3 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-4-4-4 Removal Procedure
1) Remove the RH-side cover from the system.Refer section 8-4-1 on page 32
2) Remove the LH-side cover from the system.Refer section 8-4-2 on page 34
Figure 8-40 Front cover
3)Remove the two screws (A,B) LH- side of the system. Refer Figure 8-41 on page 8-38
Front Cover
