GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
Chapter 10 Care & Maintenance 10-9
10-5-2-2 Peripheral/Option Checks
If any peripherals or options are not part of the system configuration, the check can be omitted. Refer
to the User Manual for a list of approved peripherals/options.
10-5-3 Input Power
10-5-3-1 AC Power Inspection
10-5-4 Cleaning
10-5-4-1 General Cleaning
Table 10-8 GE Approved Peripheral/Hardware Option Functional Checks
Step Item Description
1 B/W Printer
Verify hardcopy output of the B/W video page printer. Clean heads and covers if necessary.
2 Color Printer
Verify hardcopy output of the Color video page printer. Clean heads and covers if necessary.
3DICOM
Verify that DICOM is functioning properly. Send an image to a DICOM device.
4 Footswitch
Verify that the footswitch is functioning as programed. Clean as necessary.
5 ECG
Verify basic operation with customer.
6 DVD
Verify that the DVD is functioning properly. Clean heads and covers if necessary.
Table 10-9 AC Inspection
Step Item Description
1 Unplug Cord
Disconnect the mains cable from the wall and system.
2Inspect
Inspect it and its connectors for damage of any kinds.
3Verify
Verify that the LINE wires are properly attached to the terminals, and that no strands may cause a short
circuit.
Table 10-10 General Cleaning
Step Item Description
1 Console
Use a fluid detergent in warm water on a soft, damp cloth to carefully wipe the entire system. Be careful
not to get the cloth too wet so that moisture does not enter the console.
2 Probe Holder
Clean probe holders. (they may need to be soaked to remove excess gel).
3LCD
Use a soft, non-abrasive folder cloth. Gently wipe the LCD face. DO NOT use a glass cleaner that has a
hydrocarbon base (such as Benzene, Methy Alcohol or Methy Ethyl Ketone) on LCD with the filter (anti-
glare shield).
