GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
8-28 Section 8-3 - Keyboard Rear Cover Assy (FRU P/N: 5315122)
Section 8-3Keyboard Rear Cover Assy (FRU P/N: 5315122)
This is a description on how to remove and replace the keyboard cover Assembly.
8-3-0-1 Tools
• Common phillips screwdrivers
8-3-0-2 Needed Manpower
• 1 person, 15 minutes
8-3-0-3 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-3-0-4 Removal procedure
1) Remove Keyboard assembly. Refer Section 8-2-6
Figure 8-30 Keyboard
2) Remove the 2 screws (A,B) as shown in the figure above.
3) Remove LCD Arm cover as mentioned. Refer section 8-2-4 on page 8- 7
To Next Page
