IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
Chapter 4 Functional Checks 4-1
Chapter 4
Functional Checks
Section 4-1
Overview
4-1-1 Purpose for Chapter 4
This chapter provides procedures for quickly checking major functions of the LOGIQ P3 console,
diagnostics by using the built-in service software, and power supply adjustments.
Section 4-2
Required Equipment
To perform these tests, you'll need any of the sector, linear, or convex transducers.
(normally you should check all the transducers used on the system)
Section Description Page Number
4-1
Overview
4-1
4-2
Required Equipment
4-1
4-3
General Procedure
4-2
4-4
Software Configuration Checks
4-37
4-5
Peripheral Checks
4-37
Table 4-1 Contents in Chapter 4
