LOGIQ P3 S
ERVICE
M
A
NUAL
9-4
Section 9-4 - LCD Assy
Section 9-4
LCD Assy
Figure 9-2 LCD Assy
Table 9-2 LCD Assy
Item
Part Name
Descriptio
n
Quantity
100
5315112-1
LCD Display Assembly -LP3
1
5396925-1 (LP3 BT10)
LCD Display Assembly -LP3 BT
1
100
297
299
