GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
Chapter 2 Pre Installation 2-3
2-2-2 Electrical Requirements
NOTE: GE requires a dedicated power and ground for the proper operation of its Ultrasound
equipment. This dedicated power shall originate at the last distribution panel before the system.
Sites with a mains power system with defined Neutral and Live:
The dedicated line shall consist of one phase, a neutral (not shared with any other circuit), and a full
size ground wire from the distribution panel to the Ultrasound outlet.
Sites with a mains power system without a defined Neutral:
The dedicated line shall consist of one phase (two lines), not shared with any other circuit, and a full
size ground wire from the distribution panel to the Ultrasound outlet.
Please note that image artifacts can occur, if at any time within the facility, the ground from the main
facility's incoming power source to the Ultrasound unit is only a conduit.
2-2-2-1 LOGIQ P3 Power Requirements
Table 2-4 Electrical Specifications for LOGIQ P3
PARAMETER AREA LIMITS
Voltage Range (LOGIQ P3)
100-120V
100 VAC
± 10% (90-110 VAC)
220-240V 230 VAC ±10% (207-253 VAC)
Voltage Range (LOGIQ P3 BT10) 100-240V
±10%
Power All applications MAX. 425VA
Line Frequency All applications 50/60Hz (±2Hz)
Power Transients All applications
Less than 25% of nominal peak voltage
for less than 1 millisecond for any type of
transient, including line frequency,
synchronous, asynchronous, or
aperiodic transients.
Decaying Oscillation All applications
Less than 15% of peak voltage for less
than 1 millisecond.
