GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
Chapter 3 - Setup Instructions 3-47
3-7-5-1 UP-D897 - Printer Settings
1.) Call up the ‘Printer Preferences’; operation see: Section 3-7-5 "Adjustment of Printer Settings" .
2.) Select the
LAYOUT page (see: Figure 3-48 below) and select:
- Paper: 960x1280
- Orientation: Portrait
- Interpolation Method: Bilinear
3.) Select the
DENSITY ADJUST page (see: Figure 3-48 above) and select:
- Gamma: TONE2
- Advanced = 0; Dark = 0; Light = 0 ; Sharpness = 2
4.) For saving the adjusted printer settings click APPLY
and then OK.
Finally close the ‘Printers’ -window with the close button and exit System Setup with SAVE&EXIT
.
5.) Assign the Printer to the remote keys P1
, P2, and/or P3/DVR with the save button;
see: Section 3-7-6 "Remote Control Selection" on page 3-53.
Figure 3-48 Layout + Density Adjust page
