5-38 Section 5-10 - Power Distribution

Section 5-10

Power Distribution

5-10-1 ACFE - Primary Power Module

Figure 5-18 Primary Power Module

Circuit breaker

pull-out protection

Mains Power cable

Equipotential connection

Mains voltage indicator

(shows input voltage level)
