GE Voluson P8 Service Manual

GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
Chapter 7 - Diagnostics/Troubleshooting 7-57
7-12-6 DVD/CD+R/RW Drive Test
NOTE: Only DVD+R/RW and CD+(R)W medias are available.
1.) Insert an empty DVD/CD+R/RW into the Drive.
2.) Enter “Patient Archive” by pressing the PATIENT
key on the control panel.
3.) On the left side of the screen select ARCHIVE
as shown in Figure 7-57 ABOVE.
4.) If not already selected, choose Source “Local Archive” Drive from the pop-up menu.
5.) Select an Exam (with images).
Figure 7-57 Patient Archive - ARCHIVE
select Exam
(with images)
Archive
choose Source

GE Voluson P8 Specifications

General

Category	Ultrasound System
Probe Ports	3 active probe ports
DICOM	Yes
Power Requirements	100-240 VAC, 50/60 Hz
Applications	Obstetrics, Gynecology
Imaging Modes	Color Doppler, Power Doppler
Connectivity	Ethernet, USB
Operating System	Windows-based
