GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
Chapter 4 - Functional Checks 4-33
4-4-11 Erasing DVD/CD
1.) Press the F2 key on the control panel.
2.) In the “Utilities” menu select SYSTEM SETUP
to invoke the setup desktop on the screen.
3.) On the left side of the screen select CONNECTIVITY
and then click the DRIVES tab.
4.) Click the ERASE CD
button to displays the “Erase DVD/CD” window as shown in Figure 4-18.
5.) Select the “Erase Mode” and click the [OK] button to start the process.
6.) When erasing is finished, select EXIT
to return to the Scan Mode.
Figure 4-17 System Setup - Connectivity - DRIVES page
NOTICE
!! NOTICE:
It is highly recommended to use the complete erase mode, to avoid problems with the CD+(R)W!
When using a DVD+R/RW, just the fast erase mode is possible.
Figure 4-18 Erase DVD/CD Window
