GE HEALTHCARERAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
8-52 Section 8-23 - Replacement of the CASTER
Section 8-23
Replacement of the CASTER
8-23-1 Manpower
One person, 10 minutes
8-23-2 Tools
Monkey Wrench
8-23-3 Preparations
1.) Power Off/Shutdown the system as described in 4-3-2 on page 4-4.
NOTE: Lock casters before removing them.
8-23-4 Removal Procedure
1.) Remove the SIDE TRAY and CASTER CAP as explained above.
2.) Unfasten the NUT. And pull out the CASTER. Refer to the figure below.
Figure 8-63 Unfasten the NUT

GE Voluson P8 Specifications

General

Category	Ultrasound System
Probe Ports	3 active probe ports
DICOM	Yes
Power Requirements	100-240 VAC, 50/60 Hz
Applications	Obstetrics, Gynecology
Imaging Modes	Color Doppler, Power Doppler
Connectivity	Ethernet, USB
Operating System	Windows-based
