5-44 Section 5-10 - Power Distribution
5-10-2 ACDC - primary DC Power Supply
5-10-2-1 Function of ACDC
With the AC input voltage from the ACFE, the ACDC module generates 12Vdc
5-10-3 DCDC - main DC Power Supply
With the 12Vdc from ACDC, the DCDC module generates all DC power sorces:
• Front end voltages
• Standby voltage
• Tx voltages
•DVD supply
• 4D module supply
•Fan supply
5-10-4 4D Module
In addition, the AC/DC device contains the digital motor amplifier.
5-10-4-1 Rotation of the Control Console
5-10-4-2 Height Adjustment of the OPIO Console
Press the ‘Rotate’ button in the outside of the front handlebar to rotate the OPIO to the desired position.
Release the ‘Rotate’ button in order to secure the console against movement.
OPIO height adjustment is done with the button in the outside of the front handlebar.
As long as this key is pressed, OPIO can be elevated UP or DOWN by manually
To Next Page
