GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
Chapter 4 - Functional Checks 4-49
Section 4-7
Peripheral Checks
Check that peripherals work as described below:
4-7-1 ECG Check Out
Connect the USB ECG and check :
4-7-2 Control Console Positioning
The control console can be adjusted to a fixed height (910 mm) with an Extender Kit (H46882LG).
4-7-2-1 Assembly procedure for converting Voluson P6/P8 from Low Version to High Version
Table 4-14 Peripheral Checks
Step Task to do Expected Result(s)
1
Press the FREEZE key. Stop image acquisition.
2
Press the remote key (P1
, P2, P3 )
which is assigned to the BW printer.
The image displayed on the screen is printed on the Black & White
printer.
3
Press the remote key (P1
, P2, P3 )
which is assigned to the color printer.
The image displayed on the screen is printed on the Color printer.
4
Press the remote key (P1
, P2, P3 )
which is assigned to recorder control.
Recording starts/stops.
Step Task Expected Result(s)
1
Press the F2 key on the control panel and then
press the “ECG Line” button to display the ECG
signal.
It will display a curve along the bottom edge of the image sector.
Table 4-15 Part list of LCD cable and LCD Arm cover
GEPN Description Qty
5444914 Tetris LCD cable 1
5310093 LCD ARM Cover 1
2159634 SCREW BH M4X10 2
To Next Page
