GE HEALTHCARERAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
5-58 Section 5-15 - LINUX - Voluson Maintenance System
5-15-3 Before Recovering or Initializing the Hard disk
1.) Boot up the system, connect a probe and start any user program.
2.) Press the F2
key on the control panel.
3.) In the Utilities menu, select SYSTEM SETUP
to invoke the setup desktop on the screen.
4.) On the left side of the screen select ADMINISTRATION
:
- Click the OPTIONS tab to see which options are currently installed in the system.
Please print out this page or write down the “Permanent Key”
If this was not possible, contacting the OLC will be necessary.
- Click the SYSTEM INFO tab and check Software Version and date of the “Factory Settings”
(see:Section Figure 7-1 "System Setup - Administration - SYSTEM INFO page (e.g., VP8)"
on page 7-3 ).
5.) On the left side of the screen select BACKUP
:
- Click the SYSTEM CONFIGURATION
tab and then click on the SAVE button of the “Full
System Configuration” group. Select destination, enter description and then click on NEXT.
For more details about “Full Backup” see: Section 4-5-3 on page 4-37.
- Click the IMAGE ARCHIVE
tab and then click on SAVE.
Select destination, enter the description and then click on NEXT
.
For more details about saving the Patient Image Archive, see: Section 4-4-10 "Patient Archive
(Image Management)" on page 4-32
6.) On the left side of the screen select CONNECTIVITY
:
- Click the PERIPHERALS
tab and print out or write down the settings of this page.
- Click the BUTTON CONFIGURATION
tab and print out or write down the settings of this
page.
- Click the DEVICE SETUP
tab and then click on
• the [DICOM Configuration] button and print out the “DICOM Configuration” dialog page or write
down the DICOM parameters (AE Title, Station Name, Retry Count and Retry Interval).
• the [Network Configuration] button and print out the “Internet Protocol (TCP/IP) Properties” dialog
page or write down the IP settings.
7.) On the left side of the screen select GENERAL
:
CAUTION
If the system is still responsive (system starts up without problems and the application software
is running as usual, try to print out or write down System Setup and Measure Setup settings;
because they could be lost. Even if most of these settings can be restored after the installation,
it is strongly recommend to record them before starting the procedure.
Disconnecting ALL external USB devices (except DVD/CD+R/RW drive) is NECESSARY.
Re-adjusting those settings and re-installation of any previously attached printer has to be done
after the recovery procedure
CAUTION
If the system is suspected to be infected with a virus, it is highly recommended to disconnect
the network cable before starting the system.
NOTICE
If the currently installed software has to be upgraded to a newer version, and the system DVD being
used is SW 13.0.0 or higher, a new software specific “Permanent key” is required.
To Next Page
