GE HEALTHCARERAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
4-38 Section 4-5 - Backup and Restore Database, Preset Configurations and Images
4-5-2-3 Load only parts of the “Complete Backup”
NOTE: Following procedure should be used, if the user has saved own User Programs, 3D/4D Programs or
AutoText entries, but new presets have to be added to match the installed Application Software version
(e.g., User Programs and 3D/4D Programs for new probe, etc.).
1.) Perform Preparations on page 4-36.
2.) Click the +
sign (next to “Complete Backup”) to open the content tree.
3.) Click the +
sign next to “UserPrograms”, select the desired probe(s) and copy the content by clicking
the >>
button.
4.) Click the +
sign next to “3D/4D Programs”, select the desired probe(s) and copy the content by
clicking the >>
button.
NOTE: To return selected items from the “Load Data” field to “Backup Data” field select the <<
button.
5.) Confirm selection with the LOAD
button.
Settings will be loaded and the US Application Software restarts.
Figure 4-23 Load image settings for probe (e.g., RAB4-8-D)
copy desired
content into
right field
[+] sign
>>
button
[Load] button
To Next Page
