Wheels
Servicing Your Honda 99
Wheels
Refer to Safety Precautions on page 27.
Keeping the wheels true (round) and maintaining
correct spoke tension is critical to safe motorcycle
operation. During the first few rides, spokes will
loosen more rapidly due to the initial seating of the
parts. Excessively loose spokes may result in
instability at high speeds and the possible loss of
control. It’s also important that the rim locks are
secure to prevent tyre slippage.
It is not necessary to remove the wheels to perform
the recommended service in the Maintenance
Schedule (page 29). However, information for
wheel removal is provided for emergency
situations.
1. Inspect the wheel rims (1) and spokes (2) for
damage.
2. Tighten, any loose spokes and rim locks (3) to
the specified torque:
Spokes: 3.7 N·m (0.4 kgf·m, 2.7 lbf·ft)
Rim Locks: 12 N·m (1.2 kgf·m, 9 lbf·ft)
3. Check wheel rim runout. If runout is
noticeable, see an official Honda Shop Manual
for inspection instructions.
See an official Honda Shop Manual for inspection
information:
1. Check the axle shaft for runout.
2. Check the condition of the wheel bearings.
Wheel Rims & Spokes
(1) wheel rim (3) rim lock
(2) spoke
(2)
(3)
(1)
Axles & Wheel Bearings
CRF450R.book Page 99 Thursday, July 8, 2010 9:34 AM

Honda CRF450R 2011 Specifications

General

Engine Type	449cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	96.0mm x 62.1mm
Compression Ratio	12.0:1
Transmission	Close-ratio five-speed
Final Drive	#520 chain; 13T/48T
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	120/80-19
Trail	114mm (4.5 inches)
Induction	PGM-FI, 46mm throttle body
Front Suspension	48mm inverted with rebound and compression damping adjustability; 12.2 inches travel
Rear Suspension	Pro-Link single shock with rebound and compression damping adjustability; 12.4 inches of travel
Wheelbase	58.7 inches
Seat Height	37.6 inches
Fuel Capacity	1.5 gallons
