IBM SAN Volume Controller 2145-CG8 User Manual

1
Fan door A
2
Service controller
3
SATA disk drive
You can now replace the SAN Volume Controller 2145-8F4 or SAN Volume Controller 2145-8F2 disk
drive.
Replacing the disk drive
You might have to replace the disk drive for a service action.
Replacing the SAN Volume Controller 2145-CG8 or 2145-CF8 SAS boot drive
You can replace the serial attached SCSI (SAS) boot drive for the SAN Volume Controller 2145-CF8 or
2145-CG8 node.
DANGER
Multiple power cords. The product might be equipped with multiple power cords. To remove all
hazardous voltages, disconnect all power cords. (L003)
svc00322
1
2
or
1
2
svc00735
or
1
3
4
2
svc00734
svc00129
1
2
3
Figure 106. Removing the SATA disk drive
118 IBM SAN Volume Controller Hardware Maintenance Guide
|
|
|
|
|
||
|
||
|
|
