Table 4. FRUs in the SAN Volume Controller 2145-CG8 parts assembly (continued)
Assembly
index FRU part Quantity Description
- 59Y3920 1 Disk power cable
Power cable for the 2.5 inch SAS system disk. This is a Y cable;
one end connects to system board and the other two ends connect
to the two drive backplanes.
- 59Y3461 1 Backplane control cable
- 12 43V6929 6 Fan assembly
The fan assembly is used in each of the six fan positions.
- 13 81Y6625 1 System board
The system board is also called the planar.
Important: This part is the system board only. When replaced,
you must also have alcohol wipes and thermal grease.
- 14 46M0861 1 Disk controller
SAS controller card for the SAS 2.5 inch disk drive that does not
include the riser card.
- 15 43V7067 1 Disk controller riser card with USB connector
Riser card that connects the disk controller to the system board
and provides the USB port to which the service controller cable
connects.
- 16 49Y7052 0 - 1 Microprocessor
E5630 2.53 GHz 4-core microprocessor 80 W
Important: This part is the microprocessor only. A 4-core
processor must be replaced with a 4-core FRU part. When
replaced, you must also have alcohol wipes and thermal grease.
- 16 69Y4714 0 - 1 Microprocessor
IntelR XeonR Processor E5645 6-core 2.4 GHz 12 MB 5.86 GT/s
QPI 80 W
Important: This part is the microprocessor only. A 6-core
processor must be replaced with a 6-core FRU part. When
replaced, you must also have alcohol wipes and thermal grease.
Table 5. FRUs to which SAN Volume Controller 2145-CG8 service procedures do not refer
Description Part number Quantity
Node cable retention bracket 31P1402 2
Thermal grease 41Y9292 1
Heat sink 49Y4820 1
Alcohol wipes 59P4739 1
Top cover 59Y3790 1
Air baffle kit (microprocessor and memory) 59Y3779 1
Support rails 69Y4391 1
Cable management arm assembly 69Y4392 1
Chapter 1. Parts listing 5
|
|
||||
||||
|
|
|
||||
||||
|
||||
|
|
|
||||
|
|
||||
|
|
|
||||
|
|
|
|
||||
|
|
|
|
|
|
|
|
|||
|||
|||
|||
|||
|||
|||
|||
|||
|
