4. Replace the top cover. See “Replacing the top cover” on page 81.
5. Place the node in the rack. See “Replacing the SAN Volume Controller in a rack” on page 55.
6. Connect the power cable to the node and replace the cable-retention bracket. See “Replacing the
cable-retention bracket” on page 39.
7. Turn on the node.
Replacing the SAN Volume Controller 2145-8G4 operator-information panel
assembly
You might have to replace the operator-information panel on a SAN Volume Controller 2145-8G4 due to
required maintenance.
Perform the following steps to replace the operator-information panel:
1. From the front of the node, thread the light path ribbon cable through the panel housing in the node.
2. Slide the operator-information panel into its cage, as shown in Figure 226, until it locks in place with
a click (in the In position); gently pull the cable through at the back as you do this.
1
Release button
2
Operator-information panel
3. Carefully thread the light path assembly ribbon cable
4
back under its retaining brackets and
replace the tape securing it in place.
4. Thread the light path assembly ribbon cable
4
back to the system board. Reconnect the cable to
the system board socket
11
. In Figure 227 on page 229, the front of the node is shown at the bottom
of the illustration. The connectors on the cable plug go towards the center of the node and the blue
side is towards the outside of the node.
1
2
svc00258
Figure 226. SAN Volume Controller 2145-8G4 operator-information panel
228 IBM SAN Volume Controller Hardware Maintenance Guide
