Table 6. FRUs in the SAN Volume Controller 2145-CF8 parts assembly (continued)
Assembly
index Part number Units Description
- 59P4739 - Alcohol wipe
Cleaning wipe
Table 7. FRUs to which SAN Volume Controller 2145-CF8 service procedures do not refer
Description Part number Quantity
Top cover 43V6933 1
Front panel moulding that surrounds the operator information panel 49Y4818 1
Air baffle kit (microprocessor and memory) 43V6931 1
Heat sink 49Y4820 1
Base chassis 49Y4813 1
Rail kit used to install the node in a rack 49Y4816 1
Cable management arm assembly 49Y4817 1
Cable retention bracket 31P1243 1
Front panel USB cable 43V6920 1
Front bezel assembly 49Y4818 1
DVD drive bay filler 49Y4824 1
240VA safety cover 49Y4823 1
HDD I2C signal cable 43V7023 1
Table 8. FRU parts for the solid-state drive (SSD) features
Description
Part
number
Quantity Feature Code
High-speed SAS adapter
An assembly that includes a high speed SAS adapter card that provides
connectivity for up to four solid-state drive (SSD). The assembly includes
a riser card, a blanking plate, and two M3 screws.
31P1340 1
4500
High-speed SAS cable
This cable connects the high-speed SAS adapter to the disk backplane.
41Y3884 1
146 GB Solid-state drive (SSD) 31P1342 1 to 4 4601
Table 9. FRU parts for the long-wave small form-factor pluggable (SFP) transceiver feature
Description
Part
number
Quantity Feature Code
Long-wave SFP transceiver FRU
Long-wave SFP transceiver that provides an auto-negotiating 2, 4, or 8
gigabits-per-second 10 kilometer (km) long-wave optical connection on
the 4-port Fibre Channel adapter.
Note: It is possible that SFP transceiver other than those shipped with
the product are in use on the Fibre Channel host bus adapter. It is a
customer responsibility to obtain replacement parts for such SFP
transceiver. The FRU part number is shown as “Non standard - supplied
by customer” in the vital product data.
31P1345 1 to 4 5608
Chapter 1. Parts listing 9
