CAUTION:
The battery contains lithium. To avoid possible explosion, do not burn or charge the battery.
Do not:
v Throw or immerse into water
v Heat to more than 100°C (212°F)
v Repair or disassemble
Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local
regulations. In the United States, IBM has a process for the collection of this battery. For information,
call 1-800-426-4333. Have the IBM part number for the battery unit available when you call. (C003)
Use the reference numbers in parentheses at the end of each notice, such as (C003) for example, to find
the matching translated notice in IBM System Storage SAN Volume Controller Safety Notices.
Perform the following steps to replace the SAN Volume Controller 2145-8F2 or SAN Volume Controller
2145-8F4 CMOS battery:
1. Insert the new battery in the battery socket. Figure 146 shows the location (
1
of the battery socket.
a. Hold the battery so that the positive (+) side of the battery is facing toward the center of the
server.
b. Pull the retainer tab out of the way so that you can slide the battery into its socket.
c. Slide the battery down until it snaps into place, as shown in Figure 147 on page 155.
1
svc00110
Figure 146. Location of the CMOS battery on the SAN Volume Controller 2145-8F2 or the SAN Volume Controller
2145-8F4
154 IBM SAN Volume Controller Hardware Maintenance Guide
|
|
