User manual of EC160 elevator intelligent integrated machine Function parameters
94
P4_23 Weighing input selection 0~2【0】
P4_23: Weighing input selection
Set the signal input of LL, FL and OL.
0: Light load, full load and overload correspond to LL, FL and OL.
1: Select the analog input of the car. Install analog weighing sensor of DC0~10V and set after
weighing autotuning.
2: Select the analog input of the engine room. Install analog weighing sensor of DC0~10V and
set after weighing autotuning.
When LL voltage<FL voltage<OL voltage for the selected weighing
sensor, change F0_17 Bit1 to 1 (the parameter+2);
After setting P4.23 to non-zero, F0_75, F 0_76 and F0_77, obtain the
load state by setting voltage without need of load autotuning.
Function
code
Instruction Setting range【default value】 Remarks
P4_24
Weighing compensation input
channel
0-2【0】
Not modify
in running
P4_25 Pre-torque bias 0.0~100.0%【45】
P4_26
Bias and gain at the braking
side
0.000~5.000【2.000】
P4_27 Bias and gain at the drive side 0.000~5.000【2.000】
The parameter is used to set the weighing compensation input channel.
0: no compensation
1: CAN communication. Install analog weighing sensor in the bottom of the car. Send the load
signal to the main board after autotuning.
2: terminal input. Need analog weighing signal of DC0~10V output
P4_25 needs to be set to the voltage of the weighing sensor at the balance of the elevator
correctly. For example, at the balance of the elevator, the analog input voltage in drive monitoring
is 4V, and thus the parameter needs to be set to 40.0%.
When the drive is in the electromotion state, adjust P4_26.
When the drive is in the power generation state, adjust P4_27.
