User manual of EC160 elevator intelligent integrated machine Function parameters
88
Function
code
Instruction Setting range【default value】 Remarks
P3_10 Static identification current 10.0-150.0%【50】
Not modify
in running
This parameter is used to set the percentage of the identification current to the rated current of
the motor. According to the master, it can be set 40%~60%. After static autotuning, U1_07
approaches 80% and does not exceed 120%; otherwise, modify the parameter.
Function
code
Instruction Setting range【default value】 Remarks
P3_11 Pulse counting direction
0: do not change【0】
2: reverse for the synchronous
motor
4: reverse for the asynchronous
motor
Not modify
in running
When the elevator goes up, if the height of the floor is decreasing, please change the value of
P3_11.
 Please judge the counting direction when hoistway autotuning. The
real-time height of the elevator will increase when the elevator is
raising; otherwise modify the parameter.
Function
code
Instruction Setting range【default value】 Remarks
P3_12 SIN/COS encoder phase line 0~65535【0】
Not modify
in running
CD phase line selection for 1387 encoder
0: Corresponding detection of CD positive/negative signal
1: Cross detection of CD positive/negative signal
6.5.5 Parameters setting---running comfortability
【main menu】
A system control
B fault record
【parameters
setting inquiry】
P0 master drive
【P4 running
comfortability】
00 ASR low speed
