INVT EC160 User Manual

User manual of EC160 elevator intelligent integrated machine Function parameters
117
H1 logic of the car
control board
H2 front door stopping
floor
H3 rear door stopping
floor
H4 front/ rear door
stopping floor
L0 parallel and group
control setting
Function
code
Instruction Setting range【default value】 Remarks
H4_00 Front/rear door 1~8 floor 000~255【0】
Not modify
in running
H4_01 Front/rear door 9~16 floor 000~255【0】
H4_02 Front/rear door 17~24 floor 000~255【0】
H4_03 Front/rear door 25~32 floor 000~255【0】
H4_04 Front/rear door 33~40 floor 000~255【0】
H4_05 Front/rear door 41~48 floor 000~255【0】
H4_06 Front/rear door 49~56 floor 000~255【0】
H4_07 Front/rear door 57~64 floor 000~255【0】
H4_08 Reserved
Set the front/rear door stopping floor with the same method mentioned above.
6.5.16 Parameters setting---parallel and group control setting
【main menu】
A system control
B fault record
C language selection
D parameters setting
inquiry
E password setting
F system autotuning
G data management
H system information
【parameters setting
inquiry】
P0 master drive
control
P1 speed and
deceleration distance
P2 motor parameters
P3 encoder
parameters
P4 running
【L0 parallel and group
control setting】
00 Group number of the
elevator
01 Up bias floor
02 Down bias floor
03 Parallel home floor
