User manual of EC160 elevator intelligent integrated machine Function parameters
75
C language selection
D parameters setting
inquiry
E password setting
F system autotuning
G data management
H system information
[2] random running
[3] drive state
[4] main controller
[5] car controller
3. Reference frequency:
000.00Hz
4. Output frequency:
000.00Hz
5. Output speed: 0rpm
6. Output current: 0000.0A
7. Output voltage: 000.0V
8. Output power: 000.0kW
9. Bus voltage: 000.0V
6.2.4 System monitoring---main controller
【main menu】
A system control
B fault record
C language selection
D parameters setting
inquiry
E password setting
F system autotuning
G data management
H system information
【system control】
[1] calling and
running state
[2] random running
[3] drive state
[4] main controller
[5] car controller
【input signal 1-32】
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
25 26 27 28 29 30 31 32
【output relay 1-12】
1 2 3 4 5 6 7 8
9 10 11 12
【use the up/down key to
turn page and inquiry the
state and function】
Check the state of each point when the output/input point of I/O board changes and use the
UP/DOWN key to turn page and inquire the definition of the output/input point, as shown below:
【input signal 1-32】
1 low speed down
forced
speed-changing
2 low speed up forced
speed-changing
3 medium speed down
forced
speed-changing
4 medium speed up
forced
speed-changing
5 high speed down
10 inspection signal
11 inspection up
signal
12 inspection down
signal
13 up door area
14 down door area
15 middle door area
16 contact of the
safety contactor
17 contact of the
door lock contactor
18 drive output
20 brake travel switch
21 motor thermal
protection
22 fire action input
23 UPS input signal
24 high voltage
inspection of the safety
circuit
25 high voltage
inspection of the car
door lock
26 high voltage
inspection of the hall
