User manual of EC160 elevator intelligent integrated machine Debugging at fast speed
156
Select [Y] to enter
Select [Y] to enter
Select [Y] to enter
【hoistway information
autotuning】
Please ensure the
inspection state?
Please ensure whether
it is in the inspection
state?
Whether the car is in
the door area of
ground floor?
[Y] [N]
【hoistway information
autotuning】
Please ensure to begin
the hoistway information
autotuning?
[Y] [N]
【hoistway information
autotuning】
hoistway information
autotuning…
Current floor: 1
Car position: 0mm
Elevator speed: 0mm/s
After confirmation, press the inspection up button until the elevator leaves the door area and
release, and then the elevator will begin autotuning at the inspection speed and record the position
of the leveling plate and the up/down terminal deceleration switches.
(2) The manual controller will display the relative information on floor and speed.
When the elevator runs to the top door area, the system will end the autotuning and the manual
controller will display the following interface:
【hoistway information autotuning】
Succeeded.
(3) Save the autotuning data and retreat the displaying of the manual controller to the state
interface.
If failed, then
【hoistway information autotuning】
Failed.
8.5 Autotuning of the hoistway position by the up/down button
The autotuning of the hoistway position operated by the up/down button on the panel:
1. Inspect running to the door area at the bottom
2. Press the up and down buttons simultaneously for about 5s until the LED displays 1
3. Press the up button and do not release it
4. Press inspection up button, then the LED displays the floor and the decimal point flickers
5. Release the up button on the panel and inspection up button after leaving the door area
6. When the elevator runs to the door area at the top: the LED will displays “OP” if autotuning
succeeded and “Er” if autotuning failed.
