INVT EC160 User Manual

User manual of EC160 elevator intelligent integrated machine Function parameters
85
Function
code
Instruction Setting range【default value】 Remarks
the basic ones of high performance vector control, having direct impact on the performance
control.
 Do not modify above parameters without permits; otherwise, wrong
parameters may cause motor damage.
6.5.4 Parameters setting---encoder parameters
【main menu】
A
system control
B fault record
C language
selection
D parameters
setting inquiry
E password setting
F system
autotuning
G data
management
H system
information
【parameters
setting inquiry】
P0 master drive
control
P1 speed and
deceleration
distance
P2 motor
parameters
P3 encoder
parameters
P4 running
comfortability
P5 elevator
protection
parameters
P6 communication
setting
P7 drive
information
PE factory only
【P3 encoder parameters】
00 Encoder type selection
01 Encoder resolution
02 Encoder direction
03 Disconnection detection time
of the encoder at low speed
04 Disconnection detection time
of the encoder at high speed
05 Reverse detection time of the
encoder
06 Magnetic pole position
amplitude gain
07 Magnetic pole position of C
phase
08 Magnetic pole position of D
phase
09 Initial position of the
magnetic pole
10 Static identification current
11 Pulse counting direction
 Parameters of P3 will not restore to factory values.
