User manual of EC160 elevator intelligent integrated machine Function parameters
130
Function
code
Instruction Setting range【default value】 Remarks
F0_16 Test mode 0~65535【0】
Not modify
in running
0: no operation
1: allow communication reset at drive fault
8: close at fast arrival and shield calling (generally for debugging or test mode)
16: Cancel double click number clearance
64: Enable peristaltic UCM protection
The parameter is multi-function selective. Several functions can be effective simultaneously by
adding corresponding values. For example, when allowing communication reset at drive fault and
close at fast arrival, set 1+8=9.
Function
code
Instruction Setting range【default value】 Remarks
F0_17
Relative selection of CAN
communication
0~65535【0】
Not modify
in running
0: no operation
1: open protocol
2: OL voltage >FL voltage>LL voltage for weighing sensor of the car top board (also applicable to
weighing sensor of the engine room)
4: command number clearance after fast stop at door area, if not, deceleration point number
clearance
16: When the internal calling is open protocol, the external calling adopts internal protocol
connected to the external calling line or open protocol connected to the internal calling line
32: Communicating door operator
The parameter is multi-function selective. Several functions can be effective simultaneously by
adding corresponding values. For example, when clearing number at internal command of fast
stop in door area under open protocol, set 1+4=5.
When configuring calling board of the company, do not set to open
protocol.
After changing into open protocol, power on the car control board or car
