User manual of EC160 elevator intelligent integrated machine Complete product description
166
îš‹ It is recommended to use shield cables for the avoidance of
interference. Avoid parallel cable routine.
îš‹ Use 9-core cables to connect the car board and command board.
îš‹ It is better to use shield cables as the communication wires.
îš‹ Connect the terminal as designated as tight as enough.
9.1.4 Settings of configuration
Serial
No.
Door operator
and control box
configuration
BK1
terminal
DOD, PAS (F0.09=0)
1
Single control box
and single door
operator
Not
connect
F0.15=11, DOD and PAS can be the light of
opening delay button
2
Single control box
and dual door
operator
Not
connect
F0.15=1, DOD is the opening light of rear door.
Connect 4 pins of J19-DOD to 4 pins of J17, and
PAS is the light of opening delay button
3
Dual control box
and single door
operator
Short
circuit CMM
The buttons and lights of two control boxes can
be coped with in the same way.
4
Dual control box
and dual door
operator
Not
connect
DOD and PAS of front door can be multi-function
output.
9.2 Instruction of EC-CCB
EC-CCB is the auxiliary command board in the controller of EC160. Each board has 24 input and
22 output terminals, including 16 floor buttons and 8 function signals. It is mainly used for the signal
collection and output of buttons and lights. The cascade connection can meet the needs of 64
floors and the parallel connection can meet the needs of main and sub control boxes in the car.
