INVT EC160 User Manual

User manual of EC160 elevator intelligent integrated machine Function parameters
95
 P4_25, P4_26 and P4_27 are only valid when P4_24 is set to be
non-zero.
Function
code
Instruction Setting range【default value】 Remarks
P4_28
Analog input filter of car
weighing
0.00~0.50s【0.1】
Not modify
in running P4_29
Analog input filter of engine
room
0.00~0.50s【0.1】
P4_30 Smooth filter time of the curve 0~20ms【6】
6.5.6 Parameters setting---elevator protection parameters
【main menu】
A system control
B fault record
C language selection
D parameters setting
inquiry
E password setting
F system autotuning
G data management
H system information
【parameters setting
inquiry】
P0 master drive
control
P1 speed and
deceleration distance
P2 motor parameters
P3 encoder
parameters
P4 running
comfortability
P5 elevator protection
parameters
P6 communication
setting
P7 drive information
PE factory only
【P5 elevator
protection parameters】
00 Input phase loss
protection
01 Output phase loss
protection
02 Motor overload
protection
03 Motor overload
protection current
04 Overload
pre-warning threshold
05 Overload
pre-warning selection
06 Overload
pre-warning delay time
07 Automatic fault reset
times
08 Fault reset interval
09 Threshold of over
speed deviation
10 Detection time of
over speed deviation
11 Braking threshold
voltage
