User manual of EC160 elevator intelligent integrated machine Function parameters
97
Function
code
Instruction Setting range【default value】 Remarks
P5_04
Overload pre-warning
threshold
20.0%~150.0%【130.0】
Not modify
in running
P5_05 Overload pre-warning selection 0-3【0】
P5_06
Overload pre-warning delay
time
0.0~30.0s【5.0】
The value of P5_04 determines the pre-warning threshold, 100% corresponds to the rated
current of the integrated machine.
P5_05: Overload pre-warning selection, determine the overload type.
0: corresponds to the rated current of the motor, detecting all the time
1: corresponds to the rated current of the motor, detecting when constant speed
2: corresponds to the rated current of the integrated machine, detecting all the time
3: corresponds to the rated current of the integrated machine, detecting when constant speed
When the output current is more than the pre-warning threshold, the system will report fault.
Function
code
Instruction Setting range【default value】 Remarks
P5_07 Automatic fault reset times 0~3【3】
Not modify
in running
P5_08 Fault reset interval 0.1~100.0s【10.0】
When P5_07 is set to non-zero, the drive fault is allowed to reset after the interval time set by
P5_08, when the time is more than P5_07, the system will stop and need to reset after power off.
Function
code
Instruction Setting range【default value】 Remarks
P5_09
Threshold of over speed
deviation
0.1%~50.0%【20.0】
Not modify
in running
P5_10
Detection time of over speed
deviation
0.000~10.000s【0.500】
The speed detection is set to the rated speed of the elevator, the rated
frequency of the motor and encoder feedback.
