RL78/G1H CHAPTER 6 CLOCK GENERATOR
R01UH0575EJ0120 Rev. 1.20 Page 125 of 920
Dec 22, 2016
[High-speed on-chip oscillator frequency select register (HOCODIV) setting]
Address: F00A8H
Symbol76543210
HOCODIV 0 0 0 0 0 HOCODIV2 HOCODIV1 HOCODIV0
HOCODIV2 HOCODIV1 HOCODIV0
Selection of high-speed on-chip oscillator clock frequency
FRQSEL3 = 0 FRQSEL3 = 1
000f
IH = 24 MHz fIH = 32 MHz
001f
IH = 12 MHz fIH = 16 MHz
010f
IH = 6 MHz fIH = 8 MHz
011f
IH = 3 MHz fIH = 4 MHz
1 0 0 Setting prohibited f
IH = 2 MHz
1 0 1 Setting prohibited f
IH = 1 MHz
Other than above Setting prohibited
To Next Page
