RL78/G1H CHAPTER 17 EVENT LINK CONTROLLER (ELC)

R01UH0575EJ0120 Rev. 1.20 Page 540 of 920

Dec 22, 2016

CHAPTER 17 EVENT LINK CONTROLLER (ELC)

17.1 Functions of ELC

The event link controller (ELC) mutually connects (links) events output from each peripheral function. By linking

events, it becomes possible to coordinate operation between peripheral functions directly without going through the

CPU.

17.2 Configuration of ELC

Figure 17 - 1 shows the ELC Block Diagram.

Figure 17 - 1 ELC Block Diagram

Internal bus

Event control

(Link connection processor)

Event output destination select register

ELSELRn

Peripheral function

(Event receive side)

Peripheral function

(Event output side)
