RL78/G1H CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120 Rev. 1.20 Page 662 of 920
Dec 22, 2016
18.6.5 Pin state in each RF mode
Table 18 - 15 shows the pin states in each RF mode.
18.6.6 Function state in each RF mode
Table 18 - 16 shows the function states in each RF mode.
Table 18 - 15 Function State in Each RF Mode
Pin SLEEP IDLE RF Transmission RF Reception
STANDBY Low input High input High input High input
OSCDRVSE internal pin Low input
(During XTAL_RF oscillation)
High input
(During REFCLKIN_RF
external clock)
High input High input High input
DON internal pin Low input High input High input High input
RFRESETB internal pin Low input High input High input High input
INTOUT Hi-Z Operable Operable Operable
CLKOUT Hi-Z Operable Operation prohibited Operation prohibited
GPIO0
GPIO1
GPIO2
GPIO3
GPIO4
Hi-Z Operable Operable Operable
Table 18 - 16 Function State in Each RF Mode
Pin SLEEP IDLE RF Transmission RF Reception
DC-DC converter Operation stop Operation Operation Operation
Digital block Operation stop Operation Operation Operation
RF transmission/
reception circuit block
Operation stop Operation stop Operation Operation
Clock circuit
48-MHz oscillation circuit
Operation stop Operation Operation Operation
Clock circuit
Clock output circuit
Operation stop Operable Operable Operable
