RL78/G1H CHAPTER 27 FLASH MEMORY

R01UH0575EJ0120 Rev. 1.20 Page 817 of 920

Dec 22, 2016

27.4 Processing Time for Each Command When PG-FP5 Is in Use (Reference

Value)

The following shows the processing time for each command (reference value) when PG-FP5 is used as a

dedicated flash memory programmer.

Table 27 - 8 Processing Time for Each Command When PG-FP5 Is in Use (Reference Value)

Remark The command processing times (reference values) shown in the table are typical values under the following conditions.

Port: TOOL0 (single-line UART)

Speed: 1,000,000 bps

Mode: Full speed mode (flash operation mode: HS (high speed main) mode)

PG-FP5 Command

Port: TOOL0 (UART)

Speed: 1M bps

256 Kbytes 384 Kbytes 512 Kbytes

Erasing 2.5 s 3 s 4 s

Writing 6 s 8.5 s 11 s

Verification 5.5 s 8 s 10.5 s

Writing after erasing 8 s 11 s 14.5 s
