RL78/G1H CHAPTER 18 RF TRANSCEIVER

R01UH0575EJ0120 Rev. 1.20 Page 553 of 920

Dec 22, 2016

(2) Preamble value and SFD value

Set preamble length values to preamble length setting register (00A7H, 00A6H addresses) equal or more

than the below.

Table 18 - 2 For Normal Receive

Condition

Preamble length

Way Symbol rate (ksps) Modification index

2FSK/2GFSK 10 0.5 4

2FSK/2GFSK 20 0.5 4

2FSK/2GFSK 40 0.5 4

2FSK/2GFSK 50 1 4

2FSK/2GFSK 100 0.5 4

2FSK/2GFSK 100 1 4

2FSK/2GFSK 150 0.5 5

2FSK/2GFSK

200 0.5 6

2FSK/2GFSK

200 1 6

2FSK/2GFSK

300 0.5 7

4FSK/4GFSK

100 0.33 5

4FSK/4GFSK 200 0.33 6

Table 18 - 3 For Antenna Diversity Receive

Condition

Preamble length

Way Symbol rate (ksps) Modification index

2FSK/2GFSK 10 0.5 8

2FSK/2GFSK 20 0.5 8

2FSK/2GFSK 40 0.5 8

2FSK/2GFSK 50 1 8

2FSK/2GFSK 100 0.5 15

2FSK/2GFSK 100 1 15

2FSK/2GFSK 150 0.5 18

2FSK/2GFSK

200 0.5 23

2FSK/2GFSK

200 1 23

2FSK/2GFSK

300 0.5 24

4FSK/4GFSK

100 0.33 15

4FSK/4GFSK 200 0.33 23
