Renesas RL78/G1H User Manual

RL78/G1H CHAPTER 31 ELECTRICAL SPECIFICATIONS
R01UH0575EJ0120 Rev. 1.20 Page 900 of 920
Dec 22, 2016
31.7.3 DC characteristics
31.7.4 Power supply current
(TA = 25 °C, VDDRF =3.0 V, VSSRF = 0 V)
Parameter Symbol
Conditions
MIN. TYP. MAX. Unit
High-level output
current
I
OHRF GPIO0 to GPIO4
INTOUT
1.8V
≤
VDDRF
≤
3.6 V ‒2.0 mA
Low-level output
current
I
OLRF GPIO0 to GPIO4
INTOUT
1.8V
≤
VDDRF
≤
3.6 V 2.0 mA
High-level input
voltage
V
IHRF STANDBY, GPIO0 to GPIO4 0.85 VDDRF VDDRF V
Low-level input
voltage
V
ILRF STANDBY, GPIO0 to GPIO4, MODE1, MODE2 0 0.1 VDDRF V
High-level output
voltage
V
OHRF IOH = ‒2.0 mA GPIO0 to GPIO4,
INTOUT
VDDRF
‒ 0.3
V
Low-level output
voltage
V
OLRF IOL = 2.0 mA GPIO0 to GPIO4,
INTOUT
0.3 V
High-level input leak
current
I
LIHRF
VI =
V
DDRF STANDBY,
GPIO0 to GPIO4
10 μA
Low-level input leak
current
I
LILRF
VI =
V
SSRF STANDBY,
GPIO0 to GPIO4,
MODE1, MODE2
‒10 μA
(TA = 25 °C, VDDRF =3.0 V, VSSRF = 0 V)
Parameter
Conditions MIN. TYP. MAX. Unit
Transmission current (100 kbps, 2GFSK) +14.5 dBm 53 mA
+13 dBm 36
+10 dBm 21
Reception current (100 kbps, 2GFSK) During reception operation
RFIP ‒95 dBm, CW
6.9 mA
Signal reception standby
RFIP none
6.3
SLEEP mode 0.1 μA
IDLE mode 1.3 mA
