Renesas RL78/G1H User Manual

RL78/G1H CHAPTER 31 ELECTRICAL SPECIFICATIONS
R01UH0575EJ0120 Rev. 1.20 Page 901 of 920
Dec 22, 2016
31.7.5 Transceiver reception characteristics
(TA = 25 °C, VDDRF =3.0 V, VSSRF = 0 V) (1/2)
Parameter Conditions MIN. TYP. MAX. Unit
Reception sensitivity 2GFSK, BT = 0.5, BER < 0.1%,
10 kbps, m = 0.5
— ‒114 ‒109 dBm
2GFSK, BT = 0.5, BER < 0.1%,
20 kbps, m = 0.5
— ‒111 ‒106 dBm
2GFSK, BT = 0.5, BER < 0.1%,
40 kbps, m = 0.5
— ‒108 ‒103 dBm
2GFSK, BT = 0.5, BER < 0.1%,
50 kbps,
m = 1
— ‒107 ‒102 dBm
2GFSK, BT = 0.5, BER < 0.1%,
100 kbps,
m = 0.5
— ‒104 ‒99 dBm
2GFSK, BT = 0.5, BER < 0.1%,
100 kbps,
m = 1
— ‒105 ‒100 dBm
2GFSK, BT = 0.5, BER < 0.1%,
150 kbps,
m = 0.5
— ‒102 ‒97 dBm
2GFSK, BT = 0.5, BER < 0.1%,
200 kbps,
m = 0.5
— ‒101 ‒96 dBm
2GFSK, BT = 0.5, BER < 0.1%,
200 kbps,
m = 1
— ‒102 ‒97 dBm
2GFSK, BT = 0.5, BER < 0.1%,
300 kbps,
m = 0.5
— ‒97 ‒92 dBm
4GFSK, BT = 0.5, BER < 0.1%,
200 kbps,
m = 0.33
— ‒102 ‒97 dBm
4GFSK, BT = 0.5, BER < 0.1%,
400 kbps,
m = 0.33
— ‒100 ‒95 dBm
Maximum input level 2GFSK 0 12 — dBm
Spurious radiation 1 GHz or lower — — ‒57 dBm
1 GHz or higher ‒47 dBm
ED Input range 2GFSK, BT = 0.5,
100 kbps, m = 1
‒105 ‒5dBm
Total accuracy ‒66dB
RSSI Input range 2GFSK, BT = 0.5,
100 kbps, m = 1
‒100 — ‒5dBm
Total accuracy ‒6— 6dB
Relative
accuracy
‒3— 3dB
Adjacent CH
suppression
ratio
±200 kHz
(50 kbps,
m = 1)
2GFSK, BT = 0.5,
Desired signal 3 dB above the input sensitivity
level, CW interferer, BER < 0.1%
—35—dB
±400 kHz
(100 kbps,
m = 1)
—40—dB
Next-
adjacent CH
suppression
ratio
±400 kHz
(50 kbps,
m = 1
)
2GFSK, BT = 0.5,
Desired signal 3 dB above the input sensitivity
level, CW interferer, BER < 0.1%
—45—dB
±800 kHz
(100 kbps,
m = 1
)
—50—dB
