Renesas RL78/G1H User Manual

RL78/G1H CHAPTER 31 ELECTRICAL SPECIFICATIONS
R01UH0575EJ0120 Rev. 1.20 Page 896 of 920
Dec 22, 2016
31.6.3 LVD characteristics
(1) Reset Mode and Interrupt Mode
(TA = ‒40 to +85 °C, VPDR ≤ VDD ≤ 3.6 V, VSS = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Voltage
detection
threshold
Supply voltage level V
LVD2 Rising edge 3.07 3.13 3.19 V
Falling edge 3.00 3.06 3.12 V
V
LVD3 Rising edge 2.96 3.02 3.08 V
Falling edge 2.90 2.96 3.02 V
V
LVD4 Rising edge 2.86 2.92 2.97 V
Falling edge 2.80 2.86 2.91 V
V
LVD5 Rising edge 2.76 2.81 2.87 V
Falling edge 2.70 2.75 2.81 V
V
LVD6 Rising edge 2.66 2.71 2.76 V
Falling edge 2.60 2.65 2.70 V
V
LVD7 Rising edge 2.56 2.61 2.66 V
Falling edge 2.50 2.55 2.60 V
V
LVD8 Rising edge 2.45 2.50 2.55 V
Falling edge 2.40 2.45 2.50 V
V
LVD9 Rising edge 2.05 2.09 2.13 V
Falling edge 2.00 2.04 2.08 V
V
LVD10 Rising edge 1.94 1.98 2.02 V
Falling edge 1.90 1.94 1.98 V
V
LVD11 Rising edge 1.84 1.88 1.91 V
Falling edge 1.80 1.84 1.87 V
Minimum pulse width t
LW 300 μs
Detection delay time 300 μs
