Renesas RL78/G1H User Manual

RL78/G1H CHAPTER 31 ELECTRICAL SPECIFICATIONS
R01UH0575EJ0120 Rev. 1.20 Page 898 of 920
Dec 22, 2016
31.7 RF Transceiver Characteristics
31.7.1 Recommended operating conditions
31.7.2 XIN Frequency Deviation
31.7.2.1 Compatible with IEEE802.15.4g
XIN frequency accuracy is required according to the table below to satisfy the IEEE802.15.4g standard.
Parameter Conditions
MIN. TYP. MAX.
Unit
Power supply voltage 1.8 3.0 3.6 V
Operating ambient temperature
‒40
85
°C
XIN frequency 48
MHz
Operating frequency 863 928
MHz
Channel interval 12.5/200/400/600
kHz
Data rate 2FSK/GFSK 10/20/40/50/100/150/200/300
kbps
4FSK/GFSK 200/400
kbps
Modulation index 2FSK/GFSK 0.5/1.0
—
4FSK/GFSK 0.33
—
Frequency
band
[MHz]
Maximum
frequency
[MHz]
Symbol rate
[ksymbol/s]
Variable
index
MIN. TYP. MAX. Unit
IEEE
standard
863 870 50 1 ‒31.6 — 31.6 ppm 31.6
870 100 1 ‒50.0 — 50.0 ppm 50.0
870 100 0.33 ‒20.9 — 20.9 ppm 20.9
896 901 10 0.5 ‒3.1 — 3.1 ppm 3.1
901 20 0.5 ‒6.1 — 6.1 ppm 6.1
901 40 0.5 ‒12.2 — 12.2 ppm 12.2
901 902 10 0.5 ‒3.1 — 3.1 ppm 3.1
902 20 0.5 ‒6.1 — 6.1 ppm 6.1
902 40 0.5 ‒12.2 — 12.2 ppm 12.2
915 928 50 1 ‒29.6 — 29.6 ppm 29.6
928 150 0.5 ‒44.4 — 44.4 ppm 44.4
928 200 0.5 ‒50.0 — 50.0 ppm 50.0
917 923.5 50 1 ‒29.8 — 29.8 ppm 29.8
923.5 150 0.5 ‒44.6 — 44.6 ppm 44.6
923.5 200 0.5 ‒50.0 — 50.0 ppm 50.0
920 928 50 1 ‒29.6 — 29.6 ppm 29.6
928 100 1 ‒50.0 — 50.0 ppm 50.0
928 200 1 ‒50.0 — 50.0 ppm 50.0
928 200 0.33 ‒39.1 — 39.1 ppm 39.1
