Exterior and Inner Covers
SM 5 D454
Multi-Folding
Unit FD5000
D454
2. Rear lower cover [A] ( x 3)
1.1.9 TOP REAR COVER
1. Rear upper cover ( p.4)
2. Top rear cover [A] (
x 4)
1.1.10 TOP TRAY
1. Top rear cover ( p.5)
2. Inner upper cover ( p.2)
3. Release the hook [A], and remove the top tray [B] (
x 1).
1.1.11 TOP TRAY RIGHT COVER
1. Top tray ( p.5)
